| Batteries | 8 x 6V, 370 amp-hr |
| Electrical System | 48 Volts DC |
| Brakes | Spring Applied Hyd Released Discs |
| Capacity - Hydraulic Reservoir | 7.95 L |
| Machine Weight | 6831.10 kg |
| Drive Speed - Platform Lowered | 4.83 km/h |
| Gradeability - 2WD | 25 % |
| Platform Capacity | 226.80 kg |
| Platform Capacity - Unrestricted | 226.80 kg |
| Swing | 350 degrees |
| Swing Time | Non-Continuous |
| Turning Radius - Outside | 3.1 m |
| Jib - Range of Articulation | 144 degrees |
| Ground Clearance | 0.1 m |
| Machine Height | 2.01 m |
| Machine Length | 5.54 m |
| Machine Width | 1.22 m |
| Platform Dimension A | 0.76 m |
| Platform Dimension B | 4 ft |
| Tailswing | 0 m |
| Tire Size | 25 x 7 x 12 Non-Marking |
| Wheel Base | 1.65 m |
| Horizontal Jib Rotation | 0 Degrees |
| Horizontal Outreach | 6.17 m |
| Platform Height | 9.19 m |
| Up and Over Height | 4.01 m |
Learn more information about the JLG E300AJ.
Download (2.22 MB, PDF)From pre-purchase consults to end-of-lifecycle benefits, Mantrac informs, advises and partners with you.
