Collect and discharge sawdust, mulch, straw and sand into barns, stalls and orchards, backfill top soil or pea gravel into trenches and spread silage.
Designed to collect and discharge sawdust, mulch, straw and sand into barns, stalls and orchards, backfill top soil or pea gravel…
Manually adjustable discharge doors on both sides regulate the volume of discharged material. Thick plating reinforces the doors f…
Dual direction rubber conveyor belt is heavy-duty with a raised chevron tread and adjustable tension belt. Dual direction drive b…
High torque agitator assembly is directly powered by an independent hydraulic motor. Motor and conveyor systems rotate in conjunc…
Dual direct drive hydraulic motors drive the belt and a third motor drives the agitator providing consistent hydraulic flow. Motor…
Welded-on serrated safety step allows for easy entry and exit from the cab.
Tool mounted operation and maintenance manual required for proper operation of the work tool attachment is sealed from the element…
Specification | Value |
Capacity | 1.78 m³ |
Specification | Value |
Width | 2.165 mm |
Specification | Value |
Required Hydraulics | Standard Flow |
Specification | Value |
Weight | 579 kg |
Specification | Value |
Height | 1.118 mm |
Specification | Value |
Length | 1.451 mm |
Specification | Value |
Optimal Hydraulic Flow | 76-87 lpm (20-23 gpm) |
Specification | Value |
Optimal Hydraulic Pressure | 130-230 bar (2000-3300 psi) |
Specification | Value |
Belt Width | 305 mm |
Specification | Value |
Interface Type | Skid Steer Coupler |
Specification | Value |
Overall Width | 2.206 mm |
Learn more information about the Cat BD121 Side Discharge Bucket With Sawdust Agitator.
