Cat Universal 16 Reclaimer Drum (2.4 m)

Stock on demand

Price on request

Milling Width

2.438 mm

Tool Spacing

15.9 mm

Drum Diameter at Tips

1.375 mm

Request Quote Compare Models

Jump to section:

Benefits Specifications Gallery Alternatives Services Contact

US
Metric

Feature and benefits

The Universal 16 rotor is designed to produce maximum breakout force in deep asphalt cuts and on existing soil cement. It also performs well in soil stabilization applications.

Most versatile reclaimer drum

The Universal rotor is designed to produce maximum breakout force in deep asphalt cuts and on existing soil cement. It also perfor…

The Universal rotor is designed to produce maximum breakout force in deep asphalt cuts and on existing soil cement. It also performs well in soil stabilization applications.
The Universal 16 rotor may also be used in soil stabilization applications; however, the 200 bit design may result in gradation that is finer than desirable.
The large number of bits, along with the kicker paddles, will also cause this rotor to consume the most power for soil applications.

Learn More

Excellent asphalt sizing

The Universal 16 is a 406 mm) 16 in) reclaimer drum that delivers excellent asphalt sizing. The kicker paddle design provide…

The Universal 16 is a 406 mm) 16 in) reclaimer drum that delivers excellent asphalt sizing.
The kicker paddle design provides material movement and suspension in the mixing chamber and includes a breaker bar for excellent gradation in full-depth reclamation and soil stabilization applications.
Triple-tree tool placement on the rotor edges improves side cutting when maneuvering.

Learn More

Technical specification

US
Metric

Milling Width

Specification	Value
Milling Width	2.438 mm

Tool Spacing

Specification	Value
Tool Spacing	15.9 mm

Drum Diameter at Tips

Specification	Value
Drum Diameter at Tips	1.375 mm

Milling Depth (max)

Specification	Value
Milling Depth (max)	406 mm

Number of Bits

Specification	Value
Number of Bits	200

PN# of Rotor Gp with Coolant and Tools (Factory Installed)

Specification	Value
PN# of Rotor Gp with Coolant and Tools (Factory Installed)	NA

PN# of Rotor Gp with Bits (Field installed)

Specification	Value
PN# of Rotor Gp with Bits (Field installed)	287-1724

Download technical specifications

Learn more information about the Cat Universal 16 Reclaimer Drum (2.4 m).

Download (2.22 MB, PDF)
