Gas Generator Sets

Cat Gas Generator G3516H

Maximum Continuous Rating 2027 / 2007 ekW @ 1.0pf

Fuel Type Natural Gas

Maximum Electrical Efficiency 45.30%

From natural gas-fueled combined heat and power (CHP) systems and emergency power for facilities, to renewable biogas energy to support the local grid, or electricity generated from coal mine gases, Caterpillar has a wide range of reliable gas power solutions.

Feature Image
Cat G3516H Gas Engine

Robust high speed block design provides prolonged life and lower owning operationg costsDesigned for maximum performance on low pr…

  • Robust high speed block design provides prolonged life and lower owning operationg costs
  • Designed for maximum performance on low pressure pipeline natural gas
  • Simple open chamber combustion system for reliability and fuel flexibility
  • Leading edge technology in ignition system and air/fuel ratio control for lower emission and engine efficiency
  • One electronic control module handles all engine functions: ignition, governing, air/fuel ratio control and engine protection
MORE DETAILS
Feature Image
SR5 Generator

Designed to match performance and output characteristics of Caterpillar gas enginesIndustry leading mechanical and electrical desi…

  • Designed to match performance and output characteristics of Caterpillar gas engines
  • Industry leading mechanical and electrical design
  • High efficiency
MORE DETAILS
Feature Image
EMCP 4.3 Control Panel

User-friendly interface and navigationScalable system to meet a wide range of installation requirementExpansion modules and site-s…

  • User-friendly interface and navigation
  • Scalable system to meet a wide range of installation requirement
  • Expansion modules and site-specific programming for specific customer requirements
MORE DETAILS
Feature Image
Cat Electronic Control System

Simple user friendly interface and navigationDigital monitoring, metering and protection settingFully-featured power metering and…

  • Simple user friendly interface and navigation
  • Digital monitoring, metering and protection setting
  • Fully-featured power metering and protective relaying
  • Remote control and monitor capability options
MORE DETAILS
Emissions

Meets most worldwide emissions requirements down to 0.5 g/bhp-hr NOx level without aftertreatment

  • Meets most worldwide emissions requirements down to 0.5 g/bhp-hr NOx level without aftertreatment
MORE DETAILS
Proven System

Field proven in a wide range of applications worldwideFully prototype testedCertified torsional vibration analysis available

  • Field proven in a wide range of applications worldwide
  • Fully prototype tested
  • Certified torsional vibration analysis available
MORE DETAILS
Feature Image
Full Range of Attachments

Wide range of bolt-on system expansion attachmentsFactory designed and testedFlexible packaging options for easy and cost effectiv…

  • Wide range of bolt-on system expansion attachments
  • Factory designed and tested
  • Flexible packaging options for easy and cost effective installation
MORE DETAILS
Feature Image
World Wide Product Support

Cat dealers have over 1,800 dealer branch stores operating in 200 countriesYour local Cat dealer provides extensive post-sale supp…

  • Cat dealers have over 1,800 dealer branch stores operating in 200 countries
  • Your local Cat dealer provides extensive post-sale support, including maintenance and repair agreements
MORE DETAILS

Standard Equipment

Control Panels
  • EMCP4.3
Air Inlet
  • Package Mounted Air Cleaner with service indicator
  • Two-element single-stage air cleaner with enclosure and service indicator
Cooling
  • Jacket water and SCAC driven thermostats
  • ANSI Class 150/DN custom flange connections for JW inlet and outlet
  • Engine driven water pumps for jacket water and after cooler
  • 2nd stage SCAC-Cat Flange
Exhaust
  • Center section cooled turbocharger with Cat flanged outlet
  • Individual exhaust port and turbocharger outlet wired to integrated temperature sensing module (ITSM) with GCEM providing alarms and shutdowns
  • Dry exhaust manifolds, insulated and shielded
  • Cat-flanged face outlet on turbocharger
Fuel System
  • Throttle plate, 24V DC actuator, controlled by GECM
  • Electronic fuel metering valve
  • Fuel system is sized for 31.5 to 47.2 MJ/NM3 dry pipeline natural gas with pressure of 10.2 to 34.5KPa to the engine fuel control valve
Ignition System
  • Electronic Ignition System (controlled by ADEM A4)
  • Individual Cylinder Detonation Sensitive Timing (DST)
Generator
  • Permanent Magnet Excitiation
  • Anti-condensation space heater
  • Winding temperature detectors
  • SR5
  • Reactive Droop
  • Caterpillar's Digital Voltage Regulator (CDVR) with 3-phase sensing and KVAR/PF control
General
  • Crankshaft vibration damper and guard
  • Paint - Caterpillar Yellow except rails and radiators gloss black
  • RH Service
  • Parts book
  • Operation and maintenance manuals
Governing System
  • ADEM A4 4-20mA (0-5V) Speed Input
Starting/Charging
  • 24V starting motors
Air Inlet
  • Mounting brackets and piping
  • Air cleaner with precleaner
  • Heavy Duty air cleaner with precleaner
Circuit Breakers
  • No UV trip or package mounted CB Wiring
  • Frame Mounting
  • MP-Frame 3 Pole Bottom Cable Entry or MP- Frame 6 Pole Bottom Cable Entry
  • 4000A, 3-Pole IEC Rated
  • 2500/3000/3200A or 4000/5000A Neutral Current Transformer Automatic Selection
  • Lower & Upper Covers, Extension Box Roof Cover
  • Busbar Mounting
  • 4000A, 3-Pole UL Rated
Control Panels
  • Remote monitoring software
  • Discrete I/O Module, 12 Digital Inputs, 8 'Form C' Relay
  • Remote RS485, 32-light Annunciator
  • Cat Connect: Ehternet, Satellite, Cell Telematics
  • Cross-Current Compensation Current Transformer-- 8.7/15 kV Classes
  • RTD Module
  • Local/Remote PC Monitorring
  • 16 Point/32 Light Annunciator with NFPA99-110/CSA282 Configuration
  • Remote Monitoring & Control
  • Synchronizing module
  • Local alarm module
Cooling
  • Jacket water coolant heater
  • Inlet/Outlet connections
Exhaust
  • Flange
  • Muffler and spark-arresting muffler with ANSI companion flanges
  • Elbow
Generator
  • Manual voltage control
  • Generator air filter
  • Low voltage extension box
  • Medium and high voltage generators and attachment
  • Cable access box
  • Bearing temperature detectors
Starting/Charging
  • 24V Battery Charger
  • 60A, 24V charging alternator (requires engine driven pumps)
General
  • US AID emblem
  • Special paint order
  • Battery diconnect switch
  • Digital diagnostic tool
  • Tool set
  • Battery with cables and rack (shipped loose)

Technical Specifications

  • Generator Set Specifications
    Maximum Continuous Rating 2027 / 2007 ekW @ 1.0pf
    Fuel Type Natural Gas
    Maximum Electrical Efficiency 45.30%
    Frequency 50 / 60 Hz
    RPM 1500 / 1800 rpm
  • Engine Model G3516H
    Displacement 4765 in³
    Aspiration TA
    Bore 6.7 in
    Stroke 8.5 in
    Compression Ratio 12.1
    Fuel System Natural Gas
  • Length 291 in
    Width 84 in
    Height 95 in
    Dry Weight - Genset 40384 lb
